SANDEATER XTREME

SANDEATER XTREME

FULL SUSPENSION 26* X 4.0" ALL TERRAIN E-MTB

POWERED BY ULTRA M620 1000W DUAL TORQUE SENSOR MID DRIVE.

TWO REALLY FAT TYRES FOR EXTRA COMFORT AND SOFT SAND RIDING.

Do Fat bikes appeal to you ? Are you looking for an all-terrain unlimited power superior comfort electric bike ?

Chilled Squirrel started building electric Fat bikes in 2014.

11 yers later we are taking the electric fat bike design and performance to all new levels of comfort and power.

First things first - Why the Fat Wheels ?

Besides looking super cool , there are other advantages to riding an eMTB with Two Fat wheels:

• The ability to ride on a wider variety of terrain including - Beaches , Sand dunes, soft sand.
• The fatter tyres scrunch up debris and stones/rocks and absorb the bumps.

Sandeater Xtreme electric fat bike provides the following benefits:

• a high performance e-MTB Full suspension that not only performs intuitively with dual torque sensor technology but can deliver you with up to 160nM of torque when you need it.
• an aesthetically beautiful designed weld-free frame.
• the ability to adjust the components to match your ideal sitting position for comfort.
• a wide range of pedal assistance levels so that you have the freedom to ride at any level that suits your level of fitness.
• that delivers battery energy for longer rides such as e-bike touring.
• that can can ride Super comfortably on single tracks , jeep tracks , dirt roads , rough or light trails, on-road, beaches, sand dunes whilst providing a superior level of dual suspension.
• a wide range of power levels so that you are covered for the steepest of hills.
• the ability to override torque assist and pedal assist at any time in the case of an emergency or to easily take off immediately from a stationary point ( stuck in sand or from stop street or on steep hill ) by means of a small safety thumb throttle .
• Choose the group-set that matches you. Thats right , if you have a Sram or Shimano groupset that you'd prefer let us know and we can help you install it on your Sandeater Xtreme.

Does Sandeater Xtreme sound like your perfect match ? Read on to discover ...

• PROUDLY CUSTOM-BUILT & SERVICED IN SOUTH AFRICA.
• 100% SATISFACTION GUARANTEE.100% MONEY-BACK GUARANTEE.
• LIFE-TIME WARRANTY ON FRAME.
• 5 YEAR LIMITED WARRANTY.
• A TREE PLANTED IN YOUR FAMILY'S NAME BY OUR NGO PARTNER GREENPOP.ORG.

Sandeater Xtreme is Built and tested in-house in Cape Town before delivering to you.

Delivered door-to-door Nationwide in South Africa.

Chilled Squirrel builds in small batches of 10 Sandeater Xtreme's at a time to ensure quality customized eMTB delivered to you based on your requirements.

#1 The Frame

• Material : Alloy 6061
• Design : Unique sleek look - weld-less frame.
• Available Sizes : Medium 17" , Large 19" , Extra large 21"
• Artwork: High quality enamel gloss with anti-rust treatment .
• Front Fork : RST 26" RST Fat Bike Air Shock 120mm Travel
• Rear Fork : Rock Shox Deluxe.
• EU Frame safety standard-tested : EN15194

---

#2 The Motor

• Bafang M620 Ultra Max, Peak Output 1500w . Mid drive motor system.
• Super torque: 160nM.
• Dual Torque sensor technology and PAS.
• 9 levels of Pedal assist (PAS). Average speed 45km/h.
• Thumb Throttle for emergencies which Overrides Pedal assist.
• Fully reprogrammable parameters - configure to your own riding preferences.This is one of the beauties of such a versatile e-bike kit : the ability to Re-programme the settings to configures one's own personal preferences. Riders own preferences for power, speed , pedal assist ( each of the 9 levels of PAS may be adjusted ) . Via a programming tool to suit each riders style and preferences.
• Motor is Protected inside the frame from outdoor elements - rain , mud ,direct sunlight and potential knocks from rocks or other objects during riding. Motor Plates further protect against salt spray & water splash - ideal for coastal regions.
• Major benefit If you intend riding on coastal riding conditions - mid drives are a LOT more protected thatn hub drives when it comes to beach /coastal riding terrain.

---

# 3 The Battery

• BULL is a Battery that is Automatically locked-In to the frame down-tube when inserting it.
• BULL is Removable when unlocking it with a key ( Duplicate keys are included).
• BULL Battery specs ;Samsung Li ion 18-650 cells 35E 3500 mah 48v 17.5aH ( 840wH ).
• Average Range : 100km per full charge.

---

# 4 The Components & Group-set

• Air Shocks : 26* x 4.0" RST Travel 120mm.
• Rims : 80mm wide 26* x 4” .Cut-outs for lighter weight wheels.
• Hubs: Solon x36 holes Sealed bearings
• Spokes: Pillar Stainless steel
• Tyres : 26* x 4.0" Tubeless fat bike tyres
• Seat post : Zoom
• Saddle:Memory foam comfort .
• Cassette: 10 speed Shimano Deore 11-46T
• Derailleur: Shimano 10 speed Deore.
• Gear Shifter : Shimano 10 speed Deore with gear sensor
• Brakes: Tektro Hydraulic Disc e-brake cut off safety HD-E500.
• Rotors: Tektro Front wheel 180mm / Rear wheel 160mm.
• Pedals: Rockbros Wide platform.
• Handlebar : MTB riser handlebar
• Grips: Silicon comfort

* Please Note :

We are continuously looking for ways to improve performance based on the availability of improved components therefore mechanical specs may change without prior notice with the aim of improving overall product performance improvement .

All accessories shown are for reference only . Additional fees will apply if you wish to have them installed .

GUIDELINE ON FRAME CHOICE:

• Riders Height 1.65-1.75m : 17” (Medium)
• Riders Height 1.75-1.85m : 19” (Large)
• Riders Height 1.85 - 1.95 : 21" (Extra large)

We want to ensure you are 100% satisfied.
100% Money-Back Guarantee or Exchange.

Cancel your order you up to 7 days After receiving Your E-bike.

Chilled Squirrel batteries are covered by a 5 year prorated Limited warranty.

---

Our Team cares about the environment .

Working with an Incredible NGO (greenpop.org) we'll plant a tree for you.

A certificate is provided indicating GPS co-ordinates for your tree in a Nature reserve.Welcome to visit on your e-bike !
